4UDS-110 Potato Harvester
Wider three-point suspension harvester for higher direct-loading output
- 1100 mm working width
- ≥ 0.17 ha/h
- ≥ 70 HP
- Instant loading
Overview
The 4UDS-110 shares the same direct-loading harvesting system as the 4UDS family but expands the working width to 1100 mm for higher field output. Its three-point suspension layout, movable shovel and belt conveyor make it suitable for farms that want a wider tractor-mounted harvester without moving to a large bagging machine.
Key features
Wider 1100 mm intake
Expanded digging width increases throughput while keeping the same compact mounted architecture.
Higher rated output
Theoretical efficiency rises to at least 0.17 ha/h for faster harvesting in larger blocks.
Direct loading conveyor
Belt-type conveying system lifts cleaned crop upward for immediate receiving and reduced handling.
Shared service parts
Uses the same 45 mm conveyor clearance and 55CrSi chain bar material as the 4UDS-90 for consistent maintenance.
Typical applications
