Front three-quarter view — complete 4-row machine
2CML-4XS Potato Planter
Four-row high-capacity potato planter for 180 HP tractors
- Four-row large-capacity planter
- 2200 L seed tank
- 700 L fertilizer box + 350 L medicine box
- ≥ 180 HP (132 kW) tractor
Overview
The 2CML-4XS is a high-capacity four-row potato planter designed for large commercial farms. With a 2200 L seed tank, 700 L matched fertilizer box, 350 L medicine box and 3600 mm working width, it completes four-row planting in one pass and delivers working efficiency of at least 1.33 ha/h when paired with a tractor of 180 HP (132 kW) or above. Specification values in the PDF are theoretical values and should be confirmed against actual delivery configuration.
Key features
Four-row planting platform
Four aligned planting units increase daily output and support broad-acre potato operations.
Very large seed hopper
2200 L seed tank reduces refill frequency and keeps long passes efficient.
Integrated input system
Matched 700 L fertilizer box and 350 L medicine box support combined application during planting.
Heavy-duty running gear
Four wheel-type running units with 10-80-12 tires stabilize the machine under full load.
Wide working span
3600 mm working width and 900 mm ridge width suit large-scale, uniform field layouts.
High-power tractor matching
Designed for 540 r/min PTO operation with tractors of at least 180 HP.
Typical applications
